قابلیت کالیبراسیون با هوای محیط
سیگنال خروجی خطی
قابلیت آنالایز در گازهای تا 1400 درجه سانتیگراد
زمان پاسخ کوتاه
دقت بالا در بازه اندازه گیری 0 تا 21 درصد O2
|
Measuring system |
Zirconia cell current probe |
|
Measuring principle |
Current probe (current mode) probe current = lin. Ƒ (O 2 content) |
|
Probe flow for 21 vol.% O 2 |
300 to 600 mA |
|
Operating temperature of the measuring cell (sensor) |
750 to 850 ° C |
|
Heating-up time |
60 min. To operational readiness at 21% O 2 |
|
Response time after jump in measured value |
t 90 <20 s with standard gas sampling, 450 mm long |
|
Measuring range |
0-21 vol.% O 2 when calibrated with ambient air |
|
Measurement accuracy |
± 0.2 vol.% O 2 after adjustment with ambient air |
|
Protection class |
IP42 |
|
Probe signal |
0 ... 400/600 mA |
|
TÜV suitability tested |
13th and 17th BlmSchV, with lambda transmitter LT1 |
